Ortofon OM 5S Moving Magnet Cartridge

Ortofon OM 5S Moving Magnet Cartridge - Superior Sound with Spherical Stylus

Upgrade your vinyl listening experience with the Ortofon OM 5S Moving Magnet Cartridge. Boasting a spherical stylus, this cartridge offers robust and economical playback of your cherished vinyl records. Whether your tonearm features a standard headshell or a cartridge mount, the OM 5S delivers optimal sound reproduction for an immersive audio experience.

Ortofon OM 5S Key Features:

• Spherical stylus ensures precise tracking and high-fidelity sound reproduction
• Tiny, removable weight-plate allows for perfect tonearm matching
• Compatible with standard tonearms and low mass types for versatile use
• Interchangeable styli offer customization for different home systems and budgets

Ortofon OM 5 Series: Experience exceptional sound quality with the Ortofon OM 5 series, including the OM 5S, OM 5E, and Super OM 5E cartridges. As the lowest-mass range of moving magnet cartridges from Ortofon, these cartridges feature easy mounting and alignment for hassle-free setup on various headshells. Enjoy excellent compatibility with a wide range of playback systems and phono preamps for a seamless listening experience.

Ortofon OM 5S Specifications:

• Channel balance at 1 kHz: 2 dB
• Output voltage at 1 kHz, 5cm/sec: 4.5 mV
• Channel separation at 1 kHz: 20 dB
• Channel separation at 15 kHz: 12 dB
• Frequency response: 20 Hz - 20 kHz
• Tracking ability at 315Hz at recommended tracking force: 60 µm
• Compliance, dynamic, lateral: 20 µm/mN
• Stylus type: Spherical
• Stylus tip radius: R 18 µm
• Tracking force range: 1.5-2.0 g (15-20 mN)
• Tracking force, recommended: 1.75 g (17.5 mN)
• Tracking angle: 20°
• Internal impedance, DC resistance: 750 Ohm
• Cartridge color: Black/Black
• Cartridge weight: incl. extra weight 5 g, excl. extra weight 2.5 g
• Recommended load resistance: 47 kOhm
• Internal inductance: 450 mH
• Recommended load capacitance: 200-500 pF
• Replacement stylus: Stylus 5S

Elevate your listening experience with the Ortofon OM 5S Moving Magnet Cartridge, designed for audiophiles seeking superior sound quality and versatility in their home audio setup.

Ortofon OM 5S Downloads

Ortofon OM 5S User Guide
Ortofon OM5 Series Brochure
